TCHD Digital Video Technology Development (Beijing) Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | TCHD |
| Model Number : | UV8000 |
| Supply Ability : | 100 Piece/Pieces per Month wall-mounted ip camera |
| Price : | $420.00/pieces 2-3 pieces |
TCHD UV8000 camera offers perfect functions, superior performance and rich interfaces. The features include advanced ISP processing algorithms to provide vivid images with a strong sense of depth, high resolution and fantastic color rendition. It supports H.265/H. 264 encoding which makes motion video fluent and clear even with less than ideal bandwidth conditions
Technical Specification
Model | TC-UV8000 | |
Camera Parameter | ||
Optical Zoom | 12X optical zoom | |
Focal length | f=4.34~52.08mm | |
Sensor | 1/2.8 inch high quality HD CMOS sensor | |
Effective Pixels | 16: 9 2.07 mega pixel | |
Video Format | 1080P60/50/30/25/59.94/29.97;1080I60/50/59.94; 720P60/50/30/25/59.94/29.97 | |
View Angle | 7.2°(N)—68.8°(wide) | |
Iris | F1.85 ~F2.43 | |
Digital Zoom | 16X | |
Minimum Illumination | 0.5Lux (F1.8, AGC ON) | |
DNR | 2D & 3D DNR | |
White Balance | Auto / Manual/One-push /2400K/2500K/2600K/2700K/2800K/2900K/3000K/3100K/3200K /3300K/3400K/3500K/3600K/3700K/3800K/3900K/4000K/4100K/4200K/4300K/ 4400K/4500K/4600K/4700K/4800K/4900K/5000K/5100K/5200K/5300K/5400K/ 5500K/5600K/5700K/5800K/5900K/6000K/6100K/6200K/6300K/6400K/6500K/ 6600K/6700K/6800K/6900K/7000K/7100K | |
Focus | Auto/Manual/One-push | |
Iris Mode | Auto/Manual | |
Electronic Shutter | Auto/Manual | |
BLC | ON/OFF | |
Dynamic Range | OFF/ Dynamic level adjustment | |
Video Adjustment | Horizontal Flip, Vertical Flip, DCI, Super Low Illumination | |
SNR | >55dB | |
Input/Output Interface | ||
Video Interfaces | HDMI ,3G-SDI,LAN | |
Image Code Stream | Dual stream output | |
Video Compression Format | H.264, H.265 | |
Control Protocol | VISCA/Pelco-D/Pelco-P; Baud Rate: 115200/9600/4800/2400bps | |
5 Control Key | UP/DOWN/LEFT/RIGHT/CONFIRM keys for OSD setting | |
HD IP Interface | 100M IP port(100BASE-TX); Support VISCA protocol control through IP port. | |
Network Protocol | RTSP,RTMP,ONVIF, GB/T28181 | |
Power Interface | 5.0 Card line socket (DC12V) | |
Other Parameter | ||
Supply Adapter | AC110V-AC220V to DC12V/1A | |
Input Voltage | DC12V±10% | |
Input Current | 400mA(Max) | |
Consumption | 4.8W (Max) | |
Store Temperature | -10℃~+60℃ | |
Store Humidity | 20% - 95% | |
Working Temperature | -10℃~+50℃ | |
Working Humidity | 20%--80% | |
Dimension | 155.7mmX70mmX70mm | |
Weight | 0.7KG | |
Application | Indoor | |
Remote Operation (IP) | Remote Upgrade, Reboot and Reset | |
Accessory | 12V/1A Power supply, User Manual, Warranty card, brackets(optional) | |
l Superb high-definition image:Equipped with a high-quality 1/2.8-inch image sensor, capable of reaching a maximum resolution of 1920x1080 and achieving a high output frame rate of up to 60 frames per second.
l Leading Auto focus technology:Leading auto focus algorithm makes lens a fast, accurate and stable auto-focusing.
l Low noise and High SNR:Low Noise CMOS effectively ensure high SNR of camera video. Advanced 2D/3D noise reduction technology is also used to further reduce the noise, while ensuring image sharpness.
l Multiple Video Output Interfaces:Support HDMI,SDI,LAN,SDI support transmission 100 meters in 1080P format.
l Multiple Audio/Video Compression Standards:Support for H.265/H.264 compression formats;Supports up to 1920x1080 resolution compressed at 60 frames per second
|
|
