Power

Input

USB TYPE C, 25W above, Up to 20V 1A, 20W up with DC Adapter, PoE+(802.3at), CAT5e above

Consumption

~10W Max (Without DC Out)

Output

12V 1A DC Max

Video

Video Encoder

H.264 HP/MP/BPH.265 MP

Resolution

4K2160p25/30,1080p25/30/50/60,1080i50/60,720p50/60

For both video Input & Output

Frame Rate

24/25/30fps,50/60fps for 1080/720p

Codec

H.264/H.265

Rate Control

CBR/VBR

Live Preview

Web, HDMI loop through and output

Network

LAN

100/1000Mbps Gigabit

WIFI

802.11a/b/g/n/ac, Dual Band

Bluetooth

V5.0

Streaming

Streaming ln

RTSP/RTMP(s)/SRT

Streaming Decoder

RTMP(S)/SRT/RTP/UDP/RTSP

Bit Rate

Max. 50mbits/s, adjustable

NDI® Encoder

NDI®|HX3/HX2/HX

NDl® Decoder

NDI®|HX3/HX

Recorder

mp4, mov, ts

Audio

Sampling

32, 44.1, 48KHz

Encoder

AAC, MP3, 16bit

Bit rate

32-192kbps

Channel

Dual, AGC

Input

0.7VRMS,20K

Output

16ohm, 30mW

Source

HDMI Embedded, Line In

Input/Output

HDMI In

1.4b

HDMl Loop out

2.0, up 4K60

HDMI Out

1.4b, up to 4K30

Configuration

Display

Dot Matrix, COG

Setting

Mobile Phone, Pad, PC, RESTFUL

OSD

Text, Logo Caption, Time Stamp

PTZ

Interface

RS232/485/422 via USB dongle*

Protocol

Pelco D/P, VISCA

Tally

Tally

1. Green/Red Auto/Manual

Software

Firmware

Upgradeable, Linux OS

Interface

HDMI Input

1 x TYPE A, Receptacle, 1.4b

HDMI Loop Out

1 x TYPE A, Receptacle(Mux), 2.0b

HDMI Output

1 x TYPE A, Receptacle(Mux), 1.4b

Audio In

1 x 3.5mm TRS Jack

Audio Out

1 x 3.5mm TRS Jack

Interface

Network

RJ45, Gigabit, PoE

USB

1x USB,TYPEA

Visible

1 x RGB LED Panel

Alert

Buzz

Storage

Internal

1 x Micro SD/TF, USB

Network

NAS

Disk Format

FAT32 up to 2T, exFAT

*All storage media not

included

-

Physical

Size

123 x 68 x 22mm(4.8" 2.7" x 0.9")

Weight

166g(5.9oz) Black aluminum

Operating

0°C to 45°C(32F to 113°F)

Storage

-20°C to 60°C(-4°F to 140°F)

Tripod

1/4”-20UNC

Certification

CE,FCC

-
