TCHD Digital Video Technology Development (Beijing) Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | TCHD |
| Model Number : | TC312U2 |
| Price : | $387.00/pieces 1-4 pieces |
Effective Pixels: 1/2.8" high quality HD CMOS, 1080P 2.1 Megapixels
Zoom: 12X
Video Out: USB2.0
255 Preset Positions
Support SONY VISCA, PELCO P/D
IR Remote Control, RS232, IR Transparent Transmission
Horizontal Angle: ±170°; Vertical Angle: -30° to +90° degrees
Adopt 2D and 3D DNR Motion Estimation Algorithm, Low Noise CMOS Sensor
Adopt Quiet Motor, Servo Algorithm for PTZ Control, Precise location(±0.1°)
IR Remote Control Camera OSD Menu
Horizontal Speed: 0.1-100°/s; Vertical Speed: 0.1-60°/s
1080P30/25, 720P30/25 Multiple Video Formats Output
Preset Calling Speed: 100°/s; Vertical Speed: 60°/s
Widely Been Used in Video Conference System, Remote Education, Telemedicine, Church, Courts, Media Centers.
Enter/Exit Menu through IR Remote
340°Horizontal Angle; 120° Vertical Angle
IR Remote Control,RS-232C Control,
VISCA, PELCO P/D Protocol
IR Transparent Transmission,Able to Receive the Video Conference Terminal's IR Control Signal
Firmware Update Through RS-232C Port
Desktop, Ceiling Mount, Wall Mount
Compatible with Most Kinds of Video Terminal in the Market
Specfication:
Mode | TC312U2 |
Optical Parameter | |
Sensor | 1/2.8" inch Exmore CMOS |
Effective Pixels | 16:9 2.1 Megapixels |
Video Format | USB2.0: 1080p30,720p30, 640X480p30, 320X240p30, |
Optical Lens | PV312,12X,F1.6~F3.5,f=4.3mm~51.6mm ,X12 |
Horizontal View Angle | PV312,12X,62°(wide-angle)~5.2°(distal) |
Minimum illumination | 0.1Lux |
White Balance | Auto/indoor/outdoor/Manual |
Focus | Auto/Manual |
Noise-Signal Ratio | >50dB |
Input/Output interface | |
HD video interface | USB 2.0 |
Control signal interface | 8 mini DIN(RS232)/3.81 pin(RS485) |
Control signal format | Start bit:1bit,data bit:8bit,stop bit:1bit,baud rate:9600/4800/2400bps |
Power interface | HEC3800 power socket |
Support operating system | Windows 7, Windows 10, Linux |
USB protocol | UVC1.1 |
Encoding | MPEG/YUY2 |
USB interface PTZ control | USB interface PTZ control |
Mechanical Parameter | |
Pan-Tilt | Horizontal Angle: ±170°(Maximum speed: 100° /s); |
Vertical Angle: -30° to +90°(Maximum speed: 60° /s) | |
Preset accuracy:±0.1° | |
No. of Preset Positions:255 | |
Colour | Steel gray |
Power adapter | AC110V-AC220V switch DC12V/2A |
Input voltage | DC12V(DC11.5-DC12.5V) |
Power dissipation | 12W(Max) |
Storage Temperature | -10℃~+60℃ |
Working Temperature | 0℃~45℃ |
Dimensions | (Length)155 × (Width)176 x (Height)170mm |
Weight(Net weight) | 2.5KG(1.3KG) |
Environment | Indoor |
|
|
